Αναλυτική Περιγραφή
Monitor Size: 16”W (15.6” Viewable)
Panel Technology: TN TFT LCD
Resolution: HD 1366 x 768
Display Area: 344.23mm (H) x 193.54mm (V)
Aspect Ratio: 16:9
Brightness: 220 cd/m2 (Typ) w/o touch module, 190 cd/m2 (Typ) w/ touch module
Contrast Ratio: 500:1 (Typ)
Dynamic Contrast Ratio: 10,000,000:1
Viewing Angles: 90 degrees / 60 degrees (Typ)
Response Time: 12ms
Colours: 262K colours (6-bit)
Colour Gamut: 45% of NTSC (Typ)
Panel Surface: ≧7H, Haze < 2%
INPUT SIGNAL
Frequency: Fh = 30 ~ 61KHz ; Fv = 56 ~ 75Hz
Sync: Separate Sync, TMDS
COMPATIBILITY
PC: Windows 7/8/10 tested
Mac®: Display: Power Mac tested, Touch Module:iOS not support
CONNECTOR
Input: VGA x 1, HDMI x 1 (v1.4 compatible), Audio in x1 (3.5mm plug)
AUDIO: Speaker: 1W x 2, USB, Upstream: Type B x 1
POWER
Power: 5.5 x 2.1 x 11 mm DC connector
Voltage: AC 100-240V (Universal); 50/60Hz
Consumption: 5.5W
Optimize: 4.9W
Conserve: 4.3W
SPECIAL FEATURES
Eye Care: Blue light filter
ERGONOMICS
Tilt: 15 ~ 50 degrees
WALL MOUNT
VESA®: 75mm x 75mm
OPERATING CONDITIONS
Temperature (º F / º C): 32°F to 104°F (0°C to 40°C)
Humidity: 20% to 85% (no condensation)
DIMENSIONS (W X H X D) (MM)
Physical with stand (mm): 379.24mm (W) x 247.12mm (H) x 37.15mm (D) (@0 degree)
Physical without stand (mm): 379.24mm (W) x 247.12mm (H) x 37.15mm (D)
Packaging (mm): 453mm (W) x 389mm (H) x 86mm (D)
WEIGHT
Net with stand: 1.32kg
Net without stand: 1.32kg
Gross: 2.5kg
REGULATIONS
VSI: RCM, GEMS, BIS
WARRANTY
*Warranty offered may differ from market to market
PACKAGE CONTENTS
LCD Display, 40W AC/DC Adapter (1.2m), Power Cable (1.5m), VGA Cable (1.5m), USB2.0, Cable (1.8m), Audio Cable (1.8m), Quick Start Guide
